Schnelles Rendern hochdetailierter Geometrie in Echtzeit mit modernen GPUs | TU Wien

Information

Publication Type: PhD-Thesis
Workgroup(s)/Project(s):
- Rendering and Modeling
Date: 2025
Date (Start): January 2017
Date (End): April 2025
TU Wien Library: AC17547083
Open Access: yes
1st Reviewer: Marc Stamminger
2nd Reviewer: Jirí Bittner
Rigorosum: 10. April 2025
First Supervisor: Michael Wimmer
Pages: 135
Keywords: real-time rendering, GPUs, levels of detail

Abstract

Rasterization-based graphics pipelines are still essential for rendering today’s real-time rendering applications and games. We generally see high demand for efficient rasterization-based rendering techniques. With alternative approaches, such as hardware-accelerated ray tracing, it remains challenging to render more than 60 frames per second (FPS) for many real-time applications across different GPU models, or more than 90 FPS in stereo as often demanded for a smooth experience in Virtual Reality (VR) applications.In recent years, some trends emerged which put pressure on rasterization-based graphics pipelines with high geometry loads. One of these trends is VR rendering, which sometimes not only requires rendering a given scene faster and two times in every frame but some applications or settings require even more than two views to be rendered for the creation of one single frame. Another trend was mainly initiated by Epic Games’ Nanite technology, which enables the rendering of static meshes with sub-pixel geometric detail in real time. As a consequence, skinned models and other scene objects might well be expected to be rendered in similar geometric detail, increasing the geometry load even further.With this dissertation, we contribute fundamental methods and evaluations to high geometry-load scenarios in the context of real-time rendering using rasterization-based graphics pipelines to help reach the performance or quality requirements of modern real-time rendering applications and games:We contribute an in-depth analysis of the state of the art in multi-view rendering and introduce geometry shader-based pipeline variants that can help to improve compatibility and performance in challenging multi-view rendering scenarios. We describe a fundamental approach for artifact-free culling when rendering animated 3D models divided into clusters for ultra-detailed geometry scenarios. With our approach, also parts of skinned models can be culled in a fine-grained manner to match Nanite’s fine-grained culling of static clusters. In contrast to static meshes, finding conservative bounds for clusters of animated meshes is non-trivial, but is achieved with our approach. Finally, in order to render other scene objects—such as, e.g., items or generally shapes which can be described with a parametric function—in similar geometric detail, we describe a method to generate ultra-detailed geometry on the fly: After compute shader-based level of detail (LOD) determination, the resulting parametrically defined shapes are either rendered point-wise or geometry is generated on-chip using the hardware tessellator.In our research, we regard new technological developments such as hardware-accelerated multi-view rendering, new task and mesh shader stages, efficient usage of classical shader stages (such as tessellation shaders), and generally efficient usage of the vast set of features, stages, and peculiarities of modern GPUs, with the goal to accelerate real-time rendering of ultra-detailed geometry.

Additional Files and Images

thesis

Weblinks

BibTeX

@phdthesis{unterguggenberger-phdthesis,
  title =      "Schnelles Rendern hochdetailierter Geometrie in Echtzeit mit
               modernen GPUs",
  author =     "Johannes Unterguggenberger",
  year =       "2025",
  abstract =   "Rasterization-based graphics pipelines are still essential
               for rendering today’s real-time rendering applications and
               games. We generally see high demand for efficient
               rasterization-based rendering techniques. With alternative
               approaches, such as hardware-accelerated ray tracing, it
               remains challenging to render more than 60 frames per second
               (FPS) for many real-time applications across different GPU
               models, or more than 90 FPS in stereo as often demanded for
               a smooth experience in Virtual Reality (VR) applications.In
               recent years, some trends emerged which put pressure on
               rasterization-based graphics pipelines with high geometry
               loads. One of these trends is VR rendering, which sometimes
               not only requires rendering a given scene faster and two
               times in every frame but some applications or settings
               require even more than two views to be rendered for the
               creation of one single frame. Another trend was mainly
               initiated by Epic Games’ Nanite technology, which enables
               the rendering of static meshes with sub-pixel geometric
               detail in real time. As a consequence, skinned models and
               other scene objects might well be expected to be rendered in
               similar geometric detail, increasing the geometry load even
               further.With this dissertation, we contribute fundamental
               methods and evaluations to high geometry-load scenarios in
               the context of real-time rendering using rasterization-based
               graphics pipelines to help reach the performance or quality
               requirements of modern real-time rendering applications and
               games:We contribute an in-depth analysis of the state of the
               art in multi-view rendering and introduce geometry
               shader-based pipeline variants that can help to improve
               compatibility and performance in challenging multi-view
               rendering scenarios. We describe a fundamental approach for
               artifact-free culling when rendering animated 3D models
               divided into clusters for ultra-detailed geometry scenarios.
               With our approach, also parts of skinned models can be
               culled in a fine-grained manner to match Nanite’s
               fine-grained culling of static clusters. In contrast to
               static meshes, finding conservative bounds for clusters of
               animated meshes is non-trivial, but is achieved with our
               approach. Finally, in order to render other scene
               objects—such as, e.g., items or generally shapes which can
               be described with a parametric function—in similar
               geometric detail, we describe a method to generate
               ultra-detailed geometry on the fly: After compute
               shader-based level of detail (LOD) determination, the
               resulting parametrically defined shapes are either rendered
               point-wise or geometry is generated on-chip using the
               hardware tessellator.In our research, we regard new
               technological developments such as hardware-accelerated
               multi-view rendering, new task and mesh shader stages,
               efficient usage of classical shader stages (such as
               tessellation shaders), and generally efficient usage of the
               vast set of features, stages, and peculiarities of modern
               GPUs, with the goal to accelerate real-time rendering of
               ultra-detailed geometry.",
  pages =      "135",
  address =    "Favoritenstrasse 9-11/E193-02, A-1040 Vienna, Austria",
  school =     "Research Unit of Computer Graphics, Institute of Visual
               Computing and Human-Centered Technology, Faculty of
               Informatics, TU Wien ",
  keywords =   "real-time rendering, GPUs, levels of detail",
  URL =        "https://www.cg.tuwien.ac.at/research/publications/2025/unterguggenberger-phdthesis/",
}
